Digital Thermostat Temperature Controller Two Relay Output Thermoregulator for incubator Heating Cooling XK-W1088
Digital Thermostat Temperature Controller Two Relay Output Thermoregulator for incubator Heating Cooling XK-W1088, It's perfect for various household, institutional & industrial heating and cooling applications. Wholesale Digital Thermostat Temperature Controller
UKOBD2 Provide top quality Digital Thermostat Temperature Controller Two Relay Output Thermoregulator for incubator Heating Cooling XK-W1088, if you need Digital Thermostat Temperature Controller Two Relay Output Thermoregulator for incubator Heating Cooling XK-W1088, or have any questions about Digital Thermostat Temperature Controller Two Relay Output Thermoregulator for incubator Heating Cooling XK-W1088, welcome to contact us.
Wholesale Top quality VAS6154, GM Tech2, VCM II For Ford, Porsche Piwis III, USB Link 2, Scania VCI3, CAN Clip, wiTech MicroPod 2, T300 key programmer, locksmith tools
images of Digital Thermostat Temperature Controller Two Relay Output Thermoregulator for incubator Heating Cooling XK-W1088
Features:
Heating or cooling control
Red and blue dual led display
Independent Dual-way temperature controller
Temperature display resolution 0.1
Directly power output
Support high(low) temperature alarm and support for power loss (the parameters of the sudden power failure are still valid
Application range is like home temperature control, farm, various cold storage, greenhouse, aquarium, etc
Specifications:
Display Type: Digital
Material: ABS+PCB
Style:Standing Station
Temperature sensor: NTC 10K
Senor length:1.0m
Temperature measuring range:-55 ° C ~ 120 ° C / -66°F~248°F
Resolution: 0.1 ° C
Accuracy:±1° C
Power supply: 110-220VAC 50/60Hz, 12V DC , 24V DC(Please choose power supply when ordering)
Power consumption: <3W
Storage temperature: -30 ° C ~ 75 ° C
Relative humidity: 20% ~ 85% (No condensate)
Relay contact capacity: Two Relay Max 10A,Direct Output
Item Size: 7.5*5.5*3.1cm / 2.95*2.16*1.22in
Item Weight: 80g / 2.82oz
Set startup temperature:
Press the "up" button once to display the starting temperature. Long press the "up" button for about 3 seconds,The required temperature can be set by the up and down keys
Set the stop temperature:
Press the button once to display the stop temperature. Long press the button for about 3 seconds and the stop temperature number flashes. The required temperature can be set by the up and down keys
Press "Up 1" Button & "Up 2"Button at the same time to setting mode
How to restore factory Settings
press the "Down 1" and "Down 2" button at the same time, the factory setting is restored
Temperature correction
Press “Up 1 ”and “Down 1 ”at the same times for 3 second. positive value = measured value + corrected value(group 2 temperature correction is the same method )
Note:
Heating Mode--Start temperature
Code | Function | Set Range | Default |
P0 | Compressor 1 delay time | 0-60min | 0min |
P1 | Compressor2delay time | 0-60min | 0min |
P2 | High temperature alarm value | -55~120°C/-67~248°F | 120°C/248°F |
P3 | Low temperature alarm value | -55~120°C/-67~248°F | -55°C/-67°F |
Package List:
1 * Temperature Controller
2 * Waterproof Sensor
