Photon Mono X 3D Printer 8.9 inch 4K Monochrome LCD UV Resin Printers 3D Printing High Speed APP Control SLA 3D Printer
Photon Mono X 3D Printer 8.9 inch 4K Monochrome LCD UV Resin Printers 3D Printing High Speed APP Control SLA 3D Printer
UKOBD2 Provide top quality Photon Mono X 3D Printer 8.9 inch 4K Monochrome LCD UV Resin Printers 3D Printing High Speed APP Control SLA 3D Printer, if you need Photon Mono X 3D Printer 8.9 inch 4K Monochrome LCD UV Resin Printers 3D Printing High Speed APP Control SLA 3D Printer, or have any questions about Photon Mono X 3D Printer 8.9 inch 4K Monochrome LCD UV Resin Printers 3D Printing High Speed APP Control SLA 3D Printer, welcome to contact us.
Wholesale Top quality VAS6154, GM Tech2, VCM II For Ford, Porsche Piwis III, USB Link 2, Scania VCI3, CAN Clip, wiTech MicroPod 2, T300 key programmer, locksmith tools
images of Photon Mono X 3D Printer 8.9 inch 4K Monochrome LCD UV Resin Printers 3D Printing High Speed APP Control SLA 3D Printer
Photon Mono X Unboxing
Bring your vision to life
• 8.9″ 4K Monochrome LCD to achieve ultra-precision printing.
• Print size is 192mm×120mm×245mm, multiple models of the same size at one time.
• The max print speed is 60mm/h, about 3X faster than other resin 3d printers.
• Come with Anycubic APP, able to control the print operations remotely.
Ultra-high 4K resolution (3840*2400 pixels) at 8.9 inch size, highly restored details, and the screen service life is up to 2000h, more durable than ordinary RGB LCD screen.
Large Build Volume
ANYCUBIC Photon Mono X has a large printing volume of 192mmx120mmx245mm / 7.55"x4.72"x9.84", you can print multiple models of the same size at one time, saving your time and improving your productivity.
Explore larger sizes with Wash & Cure Plus
Fast Printing Speed
Do you want to finish printing faster? This printer help you to obtain higher quality models in a shorter time. Single-layer exposure only takes 1-2 seconds, and the printing speed is Max 60mm/h, which is 3 times faster than ordinary resin printers.
Anycubic APP Remote Control
You can monitor the whole UV Photocuring printing progress in real time and adjust the printing settings with ANYCUBIC app.
New Matrix UV Light Source - Higher Accuracy
Using quartz lamp beads, a new generation of new matrix design, the light source is more uniform, and can be used with 4K monochrome screen to achieve ultra-precision printing.
High Performance Z-axis - Stronger Stability
No worry about Z wobble issue, Z-axis adopts the combination of double linear guide + screw motor + anti-backlash nut, the dual Z axis rail eliminates Z-wobble, run more stable, and eliminate printing layer lines.
Efficient cooling system
Exclusive UV heat dissipation channel, efficient cooling, ensure stable printing performance and longer service life, reduce maintenance costs, and use more assured.
Anycubic Slicer Software
New features are added to the software. Supports up to 8x anti-aliasing.
- Fast slicing
- Hollowing
-Model cutting
- Lettering
Safe power supply
With UL Certification, CE marking and ETL Certification
Others Upgraded Design
①Brushed Aluminum Platform
Significantly enhances the adhesion between platform and prints.
②Marks in Resin Vat
Accurately view how much resin is left with the marks in the resin vat.
③Fully functional touch screen menu
The New UI is highly intuitive and responsive
④Safe design
Printer will be immediately shut off if the top cover has been removed.
This feature is turned off by default
Applications
Specifications
• System : ANYCUBIC Photon Mono X
• Operation : 3.5 inch Touch Screen
• Software : ANYCUBIC Photon workshop
• Connectivity : USB, Wifi
• Technology: LCD-based SLA
• Light-source: high-quality filament（wavelength 405nm）
• XY Res.: 0.050mm 3840*2400（4K）
• Z Axis Res.: 0.01 ~ 0.15mm
• Layer Res.: 0.01 ~ 0.2mm
• Printing Speed: MAX 60mm/h
• Rated Power: 120W
• Physical Dimensions
• Printer Size : 270mm(L)*290mm(W)*475mm(H)
• Build Volume: 192mm(L）*120mm(W）*245mm（H）
• Package Size: 375*395*600mm
• Material: 405nm UV Resin
• Net Weight: ~11kg
• Gross Weight:~14kg
Package List
