V-checker iOBD module B342 OBD2 Diagnosis Interface for IOS
V-checker iobd module B342 are suitable for all OBD standard cars which manufactured after 2001, with the connection between Bluetooth and module B342. Users can acquire vehicle condition (Speed, Coolant temperature, Engine speed, Fuel consumption, etc) & various of real-time warning (DTC, Over-Speed, high coolant temperature, fatigue driving) with installing APP on mobile phone.
UKOBD2 Provide top quality V-checker iOBD module B342 OBD2 Diagnosis Interface for IOS, if you need V-checker iOBD module B342 OBD2 Diagnosis Interface for IOS, or have any questions about V-checker iOBD module B342 OBD2 Diagnosis Interface for IOS, welcome to contact us.
Wholesale Top quality VAS6154, GM Tech2, VCM II For Ford, Porsche Piwis III, USB Link 2, Scania VCI3, CAN Clip, wiTech MicroPod 2, T300 key programmer, locksmith tools
images of V-checker iOBD module B342 OBD2 Diagnosis Interface for IOS
V-checker iOBD module B342 OBD2 Diagnosis Interface for IOS
Product Features
| Four display mode | Idle, Cruise, Sports, Details. |
| Multiple security alarm | Failure code, Coolant temperature, Fatigue driving, Over-speed, Etc. |
| Multiple fault diagnosis | Read DTC, Clear DTC |
| Multiple fuel consumption | Static instant fuel consumption, Dynamic instant fuel consumption, Average consumption, Etc. |
| Real time display vehicle information | Vehicle speed, Instant fuel consumption, Intake air press, Acceleration, Coolant temperature, Etc. |
Function Introduction
Vehicle DTC detection
1. Vehicle detecting automatically
Detect the vehicle at any time and anywhereFive electric control systems, the Vehicle automatically detect DTC through to the end, refuse defective vehicles hitting the road to guard users’ safe.
2. Failure analysis
Professional analysis tips, as a warm reminder.There are professional interpretation for each fault information. It could be user’s warm reminder, and give users maintenance tips, avoid blind parking to save maintenance cost.
Multiple APPs running in sync
Click ”Home”, App automatically running in the background, real-time display in the floating icon, Provide a variety of vehicle security warning (DTC, Coolant temperature, Over-Speed, etc).
Floating windows and background functions, allowing other APPs to run in sync on the phone, not only GPS navigation, but also music, video, SNS and even shopping online ,with the function of multiple APPs running in sync ,users can switch different Apps freely.
Installation instructions
APP installation: APP installation: Search "iOBD" in the App Store , then download and install software.
Please install V-checker iobd module refer to below steps strictly.
Step1: unpack the V-checker iobd module
Step2: Find the OBD connection in your car, It usually located under the steering wheel, above the brake pedal if you cannot find it ,Please contact your local 4S dealer
Step3: Turn on your ignition key, start your car, keep your car under idle mode.
Step4: Plug iobd module into OBD socket correctly the indicate will keep flashing, System will scan vehicle protocol automatically for 2 minute.
Step5: Run V-checker APP, initialize the iobd module settings refer to the steps on the screen.
Parameter
Electrical characteristics
| Input Voltage | 8 – 36 VDC |
| Working Current | 40 mA |
| Standby Current | 15 mA |
| Wireless transmission Range | With 10m open areas |
APP support two optional display interfaces: Free or Classic style. And 4 different modes available (Idle, Cruise, Sports, Details).
Display Mode: Free
Display Mode: Classic
Package Including:
1pcs x Mini packing box
1pcs x Trie Module
1pcs x User Manual
