OBDSTAR X300 DP Plus C Configuration X300 PAD2 Full Version ECU Clone+ IMMO+Odometer+ Diagnosis+ Special Functions+ P001

OBDSTAR X300 DP Plus (X300 PAD2) Key Programmer C Package Full Version

Buy OBDSTAR X300 DP Plus Get Free Convertor for Renault Talisman/Megane IV/Scenic IV/Espace V to Make Dealer Key.

Whatsapp us : +86 18259252285 if you need better price.

This device is a new Android-based vehicle trouble diagnostic device developed for internet applications. It inherits from OBDSTAR advanced diagnosing technology and it is characterized by covering wide range of vehicles, featuring powerful function, and providing precise result. Through vehicle diagnostic OBD connector and variant mobile intelligent terminals, it achieves vehicle trouble diagnosis for full car model and full system vehicle.

Meanwhile, taking advantage of mobile internet, this device integrates more application and service, such as Maintenance Database, remote assistant, One Key Upgrade etc.

OBDSTAR X300DP PLUS Key Programmer Full Package:

Diagnostic Function:

1. Diagnose the electronic control system of prevailing vehicle models covering Asian, European, American and Chinese. Diagnosis functions include: Read DTCS, Clear DTCS, Read data stream, Special functions etc.

2. Classify special function: ABS, EEPROM Adapter, Battery match, CVT learning, Instrument activation, EPB, Gear learning, Immobilizer, TPMS (low tire) reset, Cluster calibrate, ECU programming, steering angle reset.

3. Specially designed for Android platform with clear and user-friendly interface;

OBDSTAR X300 DP PAD2 Hardware Advantages:

1. Built-in VCI box, communication more stable

2. 8-inch touchscreen, more intuitionistic

3. Can be charged directly via OBD interface

4. Practical and high-end gift box

5. Industrial design with silicone case

6. Back bracket design:Can prop on the steering wheel or stand on the table, easier to operate

7. With 1 TOYOTA simulation key

8. 3 in 1, P001 programmer: combined with EEPROM adapter + RFID adapter+ Key Renew adapter

9. Add the clip of reading SOP 8PIN EEPROM

10. Add wiring harness of ECU reading by OBD (for ECU cloning and switch activation)

OBDSTAR X300 DP Plus IMMO & Odometer Car List

X300 DP PLUS Full Software Advantages:

I ECU Clone

1. ECU Clone, means ECU duplication.

The device copies all the data from the original vehicle ECU, and then writes all data copied into ECU with the same hardware to realize the same ECU function with the original vehicle.

2. Clone directly when replacing a new or a used ECU!

Without online matching in 4S store or removal of ECU bonding wire for reading and writing! Directly write without dismantling OBD!

3. Three features for ECU Clone:

A. Break monopoly from 4S, benefiting automobile maintenance industry

B. Simplified operation procedures: realize foolproof operation

C. Non-dismantling with zero risks: read and write data without dismantling ECU


II: Switch activation function

(Today many instruments or audio of vehicles activate secondary power supply to go into power-on status by relevant module CAN communication on the vehicle, but sometimes an instrument or an audio is separated from vehicle CANBUS network, causing startup failure when it needs to be repaired by an auto technician. This function can simulate CAN communication to activate secondary power supply, so the instrument or the audio enters into power-on status. In this way, it not only can test and verify the instrument or the audio, but also save an enormous cost for an auto technician to purchase a large number of startup platforms of various vehicles and wiring harnesses!)

III: Add “Help” functions

including built-in testable vehicle models, upgrade announcement, features, help notes and wiring diagrams, etc.

IV: Carlist: can directly get on the device

V: Upgrade Announcement: all details are available on the device

VI: Customers can look up the features or uniquely support functions on the device

VII: Help notes: built-in help notes for each model or function

VIII: Wiring diagrams: built-in ECU wiring diagrams, more intuitionistic and convenient

How to use OBDSTAR X300 DP Plus Induction Coil?

I. Functional Overview:
Induction Coil is used to detect the key induction coil failure of the vehicle.

II. Application Method:
Attach the Induction Coil to the key induction coil, and insert the key or turn ignition on, while Induction Coil red indicator lights up and goes out, indicating the key induction coil is good;the indicator does not illuminate to indicate the key coil is damaged, please check and repair or replace.

X-300 DP PLUS TECHNICAL PARAMETER

● Operation system: Android 5.1.1

● CPU: Exynos4418 Dual Core ARM Cortex A9 1.4GHz

● Battery: 3700mA, rechargeable polymer lithium battery

● Extension memory card: 32G Micro SD (TF) card supported

● Memory capacity:1GB

● Storage capacity: 32GB

● LCD: 8.0 inch

● LCD resolution: 1280*800

● Touch screen: Capacitive touch screen

● Camera: 5 mega rear view camera

● Wi-Fi: supported

● Working temperature: -10℃ ~ 55℃（14℉ ~ 131℉ ）

● Storage temperature: -20℃ ~ 70℃（-4℉ ~ 158℉ ）

● Weight: about 1.0 Kg

● Dimension: 254mm*174*mm*35mm

OBDSTAR X300DP Plus Software Update Instruction:

Free Update for 1 year ,after that subscription is 400USD/year

Tap “One Key Upgrade” to start downloading, enter main interface after finishing downloading. (Notes: Ensure internet connection is normal when updating. Besides, because of many software, it may take several minutes, please wait patiently) If need to cancel a software, just tap corresponding Check Box as following picture shown:

OTHER CONFIGURATIONS:

A Package:

Immobilizer+Special function(EEPROM+Key Renewing)Adapter(P001 programmer+C001circuit board+C002 circuit board+W001 cable+W002 data cable+W003 data cable+TOYOTA smart key Emulator)+others(Ignition coil+Remote tester)

B Package:

Immobilizer+Special function(EEPROM+Key Renewing)+Mileage correction+Adapter(P001 programmer+C001 circuit board+C002 circuit board+W001 data cable+W002 data cable+W003 data cable+Toyota smart key Emulator)+others(Ignition coil+Remote tester)

OBDSTAR X300 DP Plus X300 PAD2 Package List:

OBDSTAR X300 DP PLUS vs. OBDSTAR X300 DP
